othersTube & Fitting

Ultar softness enables to display excellent efficiency in piping
Superior anti-pressure, anti-vibration, anti-rust, anti-heat, anti-chemical & anti-oil.
Low-absorbtive rate, low physical performance deterioration & low changeable rate of mesuremet.
Outstanding anti-weater, anti-curve &anti-fatigue.
Lightness & softness of hose enable to increase the productivity of piping work.
Wide applicable range of temperature.
Various tube colors make it easier to distingush the pipes one another.
-20°C~80°C.

MODEL	SIZE	O/D mm	I/D mm	Thickness mm	Brust Pressure kg/cm²at20°C	Min Curvature Radius mm	Weight (g/m)	Common Pressure kg/cm²at20°C	Color
JP-0402	4×2	4	2	1.00	23	10	11	5	Transparent Yellow Blue Red Green Black
JP-0425	4×2.5	4	2.5	0.75	23	10	9	5
JP-0604	6×4	6	4	1.00	23	15	19	5
JP-0805	8×5	8	5	1.50	23	23	37	5
JP-1065	10×6.5	10	6.5	1.75	23	30	55	5
JP-1208	12×8	12	8	2.00	23	35	76	5
JP-1209	12×9	12	9	1.5	20	18	70	5
JP-1612	16×12	16	12	2	23	60	106	5
JP-0200	1/4	6.35	4.57	0.89	18	20	18	4
JP-0300	3/8	9.53	6.99	1.27	18	28	39	4
JP-0400	1/2	12.70	9.56	1.57	18	45	65	4
