Magnetic Brake & ClutchMagnetic Clutch & Brake Unit

MODEL	TORQUE(Kgf.m)		DCV	DIMENSION
MODEL	CLUTCH	BRAKE	DCV	A	B	C	D	E	H	L	M	U	V	b	d	h	i
HMCB-05	0.5	0.5	24	90	65	105	100	90	65	190	25	13	6	4	11	4	25
HMCB-10	1	1.1		110	80	130	125	110	80	240	30	15	9	5	14	5	30
HMCB-20	2	2		135	105	160	150	140	90	300	40	20	11	5	19	5	35
HMCB-40	4	4		160	135	185	190	175	112	380	50	24	11	7	24	7	40
HMCB-70	8	8		200	155	230	230	200	132	490	50	24	14	7	24	7	40
HMCB-120	12	13		200	155	230	230	200	132	500	60	28	14	7	28	7	50
HMCB-200	20	20		230	220	275	275	275	285	550	70	14	14	10	35	10	60
